Rapid Ref : DRILL-LP35P-1  Mfr Ref : DRILL-LP35P/1

JEI MiniBeast LP35+ Magnetic Drill DRILL-LP35P/1 DRILL-LP35P-1

£761.25  EX VAT
 Buy in 3 easy interest free payments of £253.75 with
Select Option

Features

Compactness and lightweight at only 9.5Kg (this mag drill is perfect for space-restricted areas).  Ultra-low fixed working height at only 176mm.  Maximum drilling diameter of 35mm with annular cutters and tungsten carbide models.  Positive quill drive for close tolerance holes.  Able to drill with twist drills with 19.05mm (3/4”) Weldon shanks.  Integrated safety guard.  Detachable feed ratchet handle that can be fitted from either side.  Lifting handle designed for easier transportation.

Product Details

Specifications

  • Spindle: 19mm
  • Machine Weight: 9.5Kg
  • Max Drilling: 35mm
  • Max Drilling Depth: 20mm with Turbo Steel annular cutters. 32mm with Turbo Tough annular cutters
  • Twist Drill Capacity: 12 mm Ø with optional Turbo Twist
  • Countersink Capacity: 30mm
  • Motor: 920 W
  • RPM: 1 Fixed Speed no load 520 RPM loaded 350 RPM
  • Height (Fixed): 176mm
  • Length x Width: 380 x 147mm
  • Magnetic Base L x W: 165 x 80mm
  • Magnet Deadlift: 910 kg on 1” Plate (8900 N)
  • Noise Level: < 90dB
  • Vibration Level: < 2.5m/s2

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
