Rapid Ref : 803084

HMT Steelbor RTQ40 Low Profile Magnet Drill with STAKIT Base 200 Case
803084

Select Option
Prices From £1088.00 ex VAT
 Buy in 3 easy interest free payments of £35.19 with

The RTQ40 fits where other drill can't, combining compact height with serious cutting power up to 40mm. Built for structural steelwork and confided access, the TG40 is the lowest profile drill in the range. With a ratchet-feed system and powerful motor, it delivers clean broaching in overhead, inside-beam or baseplate jobs other machines can't reach.

  • Only 180mm tall, perfect for restricted or confined access
  • 40mm cutting capacity with HSS or TCT cutters
  • Ratchet feed enables controlled drilling in tight areas
  • Weldon shank compatible for full tooling flexibility
  • Built-in cooling system extends cutter life and precision
  • Compact but powerful, ideal for fabrication and site work

Product Details

Specification

MAX TCT CUTTER CAPACITY 40mm
MAX HSS CUTTER CAPACITY 36mm
TWIST DRILL CAPACITY 13mm
COUNTERSINKING 32mm
LENGTH 310mm
WIDTH 135mm
HEIGHT 180mm
WEIGHT
10.8Kg
STROKE 40mm
MAGNETIC FORCE 1200Kg
MOTOR POWER 1050W
TOTAL POWER 1100W
SPEED RPM (No Load) 700RPM
SPINDLE WELDON Quick change 19.05mm 3/4" Weldon arbor for all standard broaching cutters
COOLANT SYSTEM Optional extra
WARRANTY
2 Years (When registered)

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   HMT RTQ 40 Operating Manual
