Rapid Ref : 790143012

GF 6 AVM Pipe Cutting Machine, with Automatic Feed 790143012

Click here to see what's included
£11440.00  EX VAT
 Buy in 3 easy interest free payments of £3813.33 with
Select Option

Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

The new GF series sets new standards in orbital pipe machining. Numerous innovative functions combined with an ergonomic design create significant advantages for you in the industrial prefabrication of pipeline systems. Cutting and bevelling high-alloy steel (stainless steel), low and unalloyed steel, plastics, casting materials and non-ferrous metals in just seconds, using the “Planetary Cutting” method.

GF AVM
Pipe Cutting and Bevelling Machine with automatic feed module AVM. This intelligent solution continuously controls the cutting speed depending on the torque and the parameter settings. The AVM improves the handling of the GF and RA machines and stops automatically after the cutting process. The restart inhibit does not allow an unintended start-up.

  • Anthracite-coloured coated components for improved sliding properties and protection against corrosion
  • Stainless steel clamping attachments (Code 790142241) for protection against contact corrosion included
  • Locking mechanism prevents unauthorised usage and theft
  • A new ergonomically designed motor handle for a safe and comfortable operating position, which also enables easy cutting of elbows
  • Integrated line laser to determine the cut-off point
  • 2 position clamping jaws to reduce chatter and enable smaller lengths of pipe to be machined
  • 1 multifunctional tool for all adjustments on the machine
  • Extended speed range (65 - 215rpm), ideal for the cutting of high-performance materials (Hastelloy®, P91, etc.)
  • Swivel cable with a quick-disconnect coupler for easy and quick replacement of power cables

Product Details

Machine Includes:

  • 1 Transportation Case
  • 1 Saw blade (Code 790042064)
  • 1 Set of stainless steel clamping attachments
  • 1 Mounting Plate
  • 1 Tool Set
  • 1 Tube of saw blade lubricant GF TOP
  • 1 Bottle of special gear oil
  • 1 Set of operating instructions and spare parts list
  • Quick disconnect swivel cable

Brochures, Manuals & Videos

BROCHURES & MANUALS
   View Brochure

What's Included

ORB-MANUAL  Orbitalum Operating Manual and Spare Parts List

Orbitalum Operating Manual and Spare Parts List

ORB-MOUNTING  Orbitalum Mounting Plate

Orbitalum Mounting Plate

ORB-SWCABLE  Orbitalum Quick Disconnect Swivel Cable

Orbitalum Quick Disconnect Swivel Cable
