Rapid Ref : 35.37298CVE

MOSA CS 230 YSX-CC/CV Air Cooled Diesel Welding Generator - 210A, 110V/230V 35.37298CVE

£6433.00  EX VAT
SSP Suggested Selling Price = £9190.00  YOU SAVE £2757.00
 Buy in 3 easy interest free payments of £2144.33 with
Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

The MOSA CS 230 is a 210A multi-process diesel-driven welder with Stick, MIG, Flux Cored and TIG-scratch start capability.

Features

  • High-frequency control of welding current and voltage
  • Continuous setting of current or voltage welding
  • Arc Force continuous setting
  • A.C. power available while welding
  • Yanmar air-cooled, diesel engine - 3000 rpm
  • Power optimiser (engine power optimisation system)
  • EV Engine protection
  • A.C. generator power
  • Large fuel tank (23L)
  • Meets EC directives for safety and noise level

Product Details

Specifications

  • Current range (STICK/TIG): 20 - 210A
  • Duty Cycle (STICK/TIG): 210A – 60%, 180A – 100%
  • Open circuit voltage (STICK/TIG): 65V
  • Current range: (MIG/FLUX): 15 – 30V
  • Duty Cycle (MIG/FLUX): 210A – 60%, 180A – 100%
  • Engine: Yanmar L 100 N
  • Output: 6.5kW (8.8 HP)
  • Speed: 3000 rpm
  • Fuel Consumption (welding 60%): 1.0 l/h
  • Tank Capacity: 23l
  • Running time (welding 60%): 23 hours
  • Protection: IP23
  • Dimensions: 1020mm x 645mm x 930mm
  • Dry weight: 230Kg

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   Mosa CS 230 YSX-CC/CV User Manual
