Please Note: This does not include consumables.
The industry’s only air plasma torches are designed specifically for robotic cutting and gouging.
Three torch angles: 180°, 90°, 45° – provide maximum versatility
- Choose the right torch for the application – whether you need to reach inside a part, bevel cut, or even gouge
Designed for precise positioning
- Flats, grooves, and dowel sockets on the torch body prevent rotational or horizontal slip
- Torch positioning marks for easy realignment
Compact size for easier programming
- The 90° torch measures only 20.1cm (7.9") long and 9.9cm (3.9") tall, including consumables
Durable torch lead to withstand repetitive motion
- Powermax® torch leads are lightweight and flexible to hold up under the torque and repetitive motion of robotic cutting
- Approximately 7.5cm (3") bend radius
- FastConnect™ torch quick disconnect measures 4.2cm (1.65") in diameter, making through-arm installations possible on some robots
A clamp designed for easy integration
- Optional aluminium clamp has threaded holes and bolt holes for integration with a variety of mounting arms
Mechanical teach tool aids programming
- Optional mechanical teach tool allows you to touch the plate while programming cutting and pierce heights
