FreshAir PRESSURE flow control system provides an ideal solution for workplaces equipped with breathing-quality compressed air supplies and distribution systems, or a mobile compressor. In addition, the belt-mounted FreshAir Flow Control valve includes a pressure gauge for easy monitoring of supply airflow in the workplace.

FreshAir PRESSURE Flow Control provides strong protection against a variety of airborne contaminants. The adjustment valve on the belt unit lets the user regulate airflow between 170 and 400 l/min, adapting it to individual needs and providing comfortable, reliable respiratory protection in accordance with EN 14594.

Beta 90 FreshAir and Delta 90 FreshAir headtops can be connected to the FreshAir PRESSURE Flow control system. Ideal for long work periods and more static workplace locations where mobility is not a key requirement. The FreshAir PRESSURE Flow control system offers lower initial purchase and operating costs.

Beta 90 with FA Pressure Flow Parts FAQs

Spare parts for an air-fed welding helmet used with a pressure flow supplied-air set: how to identify the right part, what wears and how to look after it.

How do I work out which spare part fits my air-fed helmet?

Start with the old part and the equipment itself. Look for the part number or marking on the worn item, then check the data plate or label on the helmet and the supplied-air unit and compare them with the parts list in the manual. Helmets from the same maker often come in several versions, so a part that looks the same may not fit.

If the old part has no readable marking, note the helmet type, the air-supply set it is used with, and the measurements of the part. Our team can help you match it, but the manual and data plate are the most reliable guide.

How do I choose the right filter lens shade?

Shade depends on the welding process, the current used and how bright the arc is. The standard for welding filters sets out recommended shade numbers for each process and current range, and the maker's chart for your helmet is the best reference. Charts usually allow one shade either side of the listed number to suit the job and your eyesight, so go a shade darker if the glare is uncomfortable.

Do not go lighter than the lowest shade the chart or the maker permits, because too light a shade can let harmful radiation reach the eyes. Do not choose a shade just for visibility without checking the chart. If you are unsure for a particular job, check it against your risk assessment or ask your supervisor.

Does the size of a replacement lens matter?

Yes. A lens has to match the opening in the helmet frame, so the width and height must be correct and the type of lens must suit the holder. Measure the old lens, or check the dimensions printed in the manual or on the lens edge, before buying a new one.

A lens that is only roughly the right size can leave gaps, sit loosely or be held badly, which can let light and spatter reach the face. Also check the filter's marking for the shade and, for auto-darkening types, the optical class. Passive filters and auto-darkening filters are marked differently, so check you are buying the right type.

What does the marking on a welding filter lens mean?

A welding filter carries a marking on the lens showing the shade or shade range, the maker's identification, an optical class and the standard it was made to. Older automatic filters carry four classes each graded 1 to 3, where 1 is the best: optical quality, light diffusion, variation in luminous transmittance and angle dependence. That older standard has been withdrawn and replaced by a newer international series, so newer filters may be marked differently.

The marking on the filter itself is the authority. Compare it with the manual for the helmet and use only the types and shades the maker approves for that helmet.
