  • 0447700910  ESAB Renegade ET 180iP Ready To Weld Package with 4m TIG Torch - 115 / 230v, 1ph
Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

Rapid Ref : 0447700910

ESAB Renegade ET 180iP Ready To Weld Package with 4m TIG Torch - 115 / 230v, 1ph 0447700910

£1204.70  EX VAT
SSP Suggested Selling Price = £1721.00  YOU SAVE £516.30
 Buy in 3 easy interest free payments of £401.57 with

* Comes included with 3m work lead, 4m SR-B 26 TIG torch, 4m gas hose and shoulder strap. *

The ultimate in durability with a portable design.

The Renegade ET is a professional single-phase, high-frequency start TIG and MMA welding machine with the most resistant IP23 housing designed to be used in demanding environments. Equipped with a high-quality carry strap with multiple lift points, Renegade is ready to move with you when portability is required.

The Renegade ET have a built-in active PFC circuit that allows it to work perfectly even on a poor-quality power supply and on very long extension cables (up to 100m). Superior weld quality is a priority in this range, additionally supported by direct access to wide parameters selection on a simple and intuitive user interface makes the machine very easy to work with.

Features

  • Highest durability housing with IP23 for indoor and outdoor use
  • TIG Pulse up to 999 Hz to increase control of heat input and weld pool
  • PFC for stable arc even with extra-long mains cable, up to 100m
  • Easy to read and quick to set panel increasing the accuracy and reducing the downtime
  • Dual-current mode trigger functionality to switch between two output current levels which control the heat input and size of the weld pool
  • Modular system with tool-less connection to a water cooler and trolley
  • ESAB SR-B TIG torch included

Product Details

Specifications

  • Mains Voltage: 115/230 VAC ±15%, 1ph, 50/60 Hz
  • Fuse Slow: 16 A
  • Rated KVA: 3.3 KVA (115 VAC), 6 KVA (230 VAC)
  • Energy save mode: <30 W
  • Welding Output MMA 115 VAC: 110A / 24.4V at 25%, 71A / 22.8V at 60%, 55A /22.2V at 100%
  • Welding Output MMA 230 VAC: 180A / 27.2V at 25%, 116A / 24.6V at 60%, 90A/ 23.6V at 100%
  • Welding Output TIG 115 VAC: 140A / 15.6V at 25%, 90A / 13.6V at 60% 70A / 12.8V at 100%
  • Welding Output TIG 230 VAC: 180A / 17.2V at 25%, 116A / 14.6V at 60%, 90A / 13.6V at 100%
  • Setting Range 115 VAC MMA: 15A / 20.6V –110A / 24.4V
  • Setting Range 230 VAC MMA: 15A / 20.6V –180A / 27.2V
  • Setting Range 115 VAC TIG: 10A / 10.4V –140A / 15.6V
  • Setting Range: 230 VAC TIG: 10A / 10.4V –180A / 17.2V
  • Power Factor Max Current: 99%
  • Open Circuit VDC High: 78 VDC
  • Enclosure class: IP23
  • Operating Temperature: -10 to +40°C (+14 to +104°F)
  • Dimensions: 460 x 200 x 320mm
  • Supply plug: CEE 16 A
  • Weight: 11Kg
