Rapid Ref : 0447101881

ESAB Fabricator ET 410iP CE Arc Welder Power Source - 400v, 3ph 0447101881

£2235.00  EX VAT
SSP Suggested Selling Price = £3192.00  YOU SAVE £957.00
 Buy in 3 easy interest free payments of £745.00 with
Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

The Fabricator ET 410iP is a heavy-duty inverter-controlled power source for HF TIG Pulse welding and MMA (Stick) welding. The Fabricator ET 410iP is built to withstand rugged use, making it a perfect solution for industrial usage. Ideal for heavy industries.

Features

  • The intuitive control panel of the ET 410iP makes it easy to optimise settings, reducing the time taken to achieve the best weld characteristics
  • Equipped with High Frequency for easy arc starts and Start Pulse (micropulse) which preheats the Tungsten electrode for improved arc stability from the start
  • Pulse background current between 10% and 90% of the set current and pulsing frequency from 0.5 to 250Hz, for optimal pulse in each application
  • Spot mode for easy tack welding and 4TS to be able to pulse only when it’s necessary
  • Wide mains voltage tolerance allows for stable welding
  • Inverter controlled for high efficiency and low power consumption
  • Excellent welding performance with Stick electrodes

Product Details

Specifications

  • Mains Voltage (Welding Input): 380-400-415-440 VAC (-15% +10%), 3 Ph,50/60 Hz
  • Fuse Slow: 32 A
  • Welding Output: 410 A / V at 60% Duty Cycle, at 40°C310 A / V at 100% Duty Cycle, at 40°C
  • Setting Range MMA/TIG: 30 –410 A / 5 –410 A
  • Pulse Background Current Settings Range: 10% to 90% of set current
  • Pulse frequency: 0.5 –250Hz
  • Efficiency Max Current: 89% MMA and 86% TIG
  • Idle power consumption: 40W (VRD OFF)15W (VRD ON)
  • Maximum Open Circuit Voltage (Max. With VRD ON): 76 VDC (15VDC)
  • Enclosure class: IP23S
  • Operating Temperature: -10 to +40°C (+14 to +104°F)
  • Certification Mark (Standard): CE
  • Dimensions LxWxH: 525 ×280 ×475 mm
  • Weight: 35.2Kg
